SPECIFICATIONS
Engine
Displacement (ml) 140
Bore×Stroke (mm) 56.5*55.5(2.22’’ * 2.19’’)
Compression Ratio 9.0:1
Max. Power (kw/r/min) 7.35/7500
Max. Torque (N.m/r/min) 10.5/6000
Max. Speed (Km/h) ≥90(≥56mph)
Lubrication Pressure and Splash
Shift type Automatic transmission
Ignition CDI
Starting System Electric/Kick start
Transmission System Chain drive
Fuel supply mode Carburetor
Oil consumption ≤2.5L/100km (41.04mph)
Environmental protection
standard EPA
Chassis
Front Brake Drum Brake (Hand lever)
Rear Brake Drum Brake (foot pedal)
Front Tire 2.50-17
Rear Tire 2.75-17
Battery 12V5Ah
Dimensions
L × W×H (mm) 1780×700×1050 (70.08’’ x 27.56’’ x 41.34’’)
Seat Height (mm) 760 (29.92’’)
Wheelbase (mm) 1220 (48.03’’)
Min.GroundClearance(mm) 200 (7.87’’)
Max.Permissionable
Weight(kg) 80 (176.4lbs)
Rider Capacity 1

Dry. Weight (kg) 75 (165.38lbs)
Engine Oil (L) 1.0 (0.264lbs)
Fuel Tank Capacity (L) 7.0 (1.85lbs)
