Engine / Drive Train Specifications

Engine: 149 cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 11.0HP/8500RPM

Max Torque: 7.38ft-lb/6500RPM

Bore × Stroke: 62mm x 49.5mm

Compression Ratio: 9.2:1

Cooling System:  Air cooled

Transmission:  5-Speed, Manual

Start System:  Kick Start or Electric Start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 55MPH

Battery:  N/A or 5Ah



Frame / Body / Suspension / Brakes

Front Suspension:  Dual hydraulic forks and shock absorbers.

Rear Suspension:  Swing arm with central shock absorber.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake.

Front Tires: 70/100-19

Rear Tires: 90/100-16



Capacities / Dimensions

Max Load: 187.43lbs

Gross Weight: 233.73lbs

Net Weight:  198.45lbs

Overall Length: 75.6inches

Overall Width: 39.3inches

Overall Height: 47inches

Carton Dimensions (L × W × H):  64.17x17.72x33.86inches

Seat Height: 32.3inches

Wheelbase:  52inches

Ground Clearance: 9.45inches

Gas Tank Capacity:  1.59gal

Fuel Consumption: 84mpg



Available colors:  Black, Red, Blue, Green.
