Engine / Drive Train Specifications

Engine: 177.3cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 12.06HP/7000-7500RPM

Max Torque: 9.74ft-lb/6000RPM

Bore × Stroke: 62.5mm x 58mm

Compression Ratio: 9.6:1

Cooling System:  Air cooled

Transmission:  Fully automatic with reverse

Start System:  Electric start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 45MPH

Battery: 12V9Ah





Frame / Body / Suspension / Brakes

Front Suspension:  Dual A-Arm with dual shock absorbers.

Rear Suspension:  Swing arm with central shock absorber.

Front Brake: Drum brake.

Rear Brake:  Hydraulic disc brake.

Front Tires: 23x7-10

Rear Tires: 22x10-10



Capacities / Dimensions

Max Load: 220.5lbs

Gross Weight: 452.03lbs

Net Weight: 385.88lbs

Overall Length: 63.39inches

Overall Width: 48.43inches

Overall Height: 43.3inches

Carton Dimensions (L × W × H):  57.88x33.86x32.29inches

Seat Height: 33.46inches

Wheelbase: 45.28inches

Ground Clearance: 5.9inches

Gas Tank Capacity: 1.45gal

Fuel Consumption: 69.18mpg



Optional:Steel Wheels or Aluminum Alloy Rim.

Available colors:  Red frame with Red body, Red frame with Black body, Blue frame with Blue body.
