Engine / Drive Train Specifications

Engine: 223cc, 4-stroke, Balance shaft

Cylinder Arrangement: Single cylinder

Max Horsepower: 16.09HP/7500RPM

Max Torque: 13.28ft-lb/5000RPM

Bore × Stroke: 65.5mm x 66mm

Compression Ratio: 9.0:1

Cooling System:  Air cooled

Transmission:  5-Speed, Manual

Start System:  Electric and Kick Start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 75MPH

Battery: 12V6.5Ah



Frame / Body / Suspension / Brakes

Front Suspension:  Dual hydraulic forks and shock absorbers.

Rear Suspension:  Swing arm with central shock absorber.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake

Front Tires: 80/100-21

Rear Tires: 110/100-18



Capacities / Dimensions

Max Load: 331lbs

Gross Weight: 315.32lbs

Net Weight: 280lbs

Overall Length: 82.3inches

Overall Width: 36.2inches

Overall Height: 56.7inches

Carton Dimensions (L × W × H):  69.69x18.11x33.86inches

Seat Height: 35.4inches

Wheelbase: 53.93inches

Ground Clearance: 8.3inches

Gas Tank Capacity: 3.7gal

Fuel Consumption: 65.34mpg



Available colors:  Black, Red, Blue, Green.
