Engine / Drive Train Specifications

Engine: 71.8cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 5.63HP/8500RPM

Max Torque: 4.13ft-lb/6500RPM

Bore × Stroke: 47mm x 49.5mm

Compression Ratio: 8.8:1

Cooling System:  Air cooled

Transmission:  Fully automatic

Start System:  Electric start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 24.86MPH

Battery: 12V/4Ah or 5Ah



Frame / Body / Suspension / Brakes

Front Suspension:  Dual hydraulic forks and shock absorbers.

Rear Suspension:  Swing arm with central shock absorber.

Front Brake: Drum brake.

Rear Brake: Drum brake.

Front Tires: 2.50-10

Rear Tires: 2.50-10



Capacities / Dimensions

Max Load: 132.3lbs

Gross Weight: 122lbs

Net Weight: 110.25lbs

Overall Length: 55.19inches

Overall Width: 25.2inches

Overall Height: 34.26inches

Carton Dimensions (L × W × H):  47'' L x14'' W x 24'' inches

Seat Height: 23.63inches

Wheelbase: 37.8inches

Ground Clearance: 5.12inches

Gas Tank Capacity: 0.53gal

Fuel Consumption: 131mpg



Optional: Training wheel

Available colors:  Red, Blue, Green, Orange.
