DF125GKS


Engine type:

125cc 4 STROKE Go - Kart

Seat:

Adjustable Bench

Transmission
System:



Automatic with Reverse

Cooling:

Air Cooled

Max Speed:

25-35MPH (Depends on the
condition of road and driver's
weight)

Exhaust:

Pipe Muffler

Starter
System:



Electric Start (CDI)

Brake
System:

Front & REAR Disc

Tire Size:

FRONT - 13x5-6"
REAR - 14.5x70-6"

L X W X H:

69" x 48" x 55"

Gauges:

Front HEADLIGHT
& TAILLIGHT

Drive:

Chain & Gear Rear Driven

Battery:

12v.6.5Ah

Gas Tank:

0.5 Gallon

Range:

10 miles

Overall
Weight:

6.5" 295 LBS.

Net Weight:

287 LBS.

Weight:

N.W:652.5/
G. W:690.2 LBS.


Basic InfoModel NameSunny A6

EngineEngine& Type139QMB

Displacement49ml

Cooling SystemAir cooled

Number of Cylinder1

Compression Ratio10.5:1

Bore x Stroke41.5

Max Power[Kw/r/m]2.4kw/8000r/min

Max Torque[N.m/r/m]2.8Nm/6500r/min

Top Speed [mph]35

Transmission Automatic

ReverseN/A

Starting SystemElectric&kick start

Final DriveBelt

Ignition TypeCDI

Carburetor typePD18JA

Battery 12V/7AH

Brake,wheelFront Brake ModeHydraulic pressure disc

Rear Brake ModeDrum

Front Tires 100/60-12/alloy rim

Rear Tires  100/60-12/alloy rim

Capacities / DimensionsWeight Capacity 330.75 LBS / 150 KG

Net Weight169.76 LBS / 77 KG

Gross Weight209.48 LBS / 95 KG

Overall Length [inch]66.14 / [mm]1680

Overall Width  [inch]24.8 / [mm]630

Overall Height  [inch]41.73 / [mm]1060

Carton DimensionsLXWXH[inch]66.54*18.11*32.28

Seat Height [inch]  32.28

Wheelbase [inch] 47.25

Min Ground Clearance[inch]5.51

Fuel Capacity [gal]1.43
