Engine Type561 cc,Single Cylinder, SOHC



Bore X StrokeØ 95 × 79.2 mm

Compression Ratio10.2

Fuel System42 mm Throttle Body / Programmed Fuel Injection

Max Power44.8 HP / 6500 rpm

Max Torque46.5 Nm / 5500 rpm

Drive System4 × 4 Shaft Drive

Gear Selection  l / H / N / R / P

Transmission  V-Belt CVT Automatic

Engine Braking System Standard

Over Ride Button Standard

Front Suspension Dual A-arm

Rear Suspension  Dual A-arm with Anti-roll Bar

Front/Rear Brake Hydraulic Disc with piston caliper and Hydraulic Foot Brake

Parking Brake  Park In Transmission / Lockable Hand Lever

Front TireAT 25 × 8 – 12 , 6 PLY

Rear TireAT 25 × 10 – 12 , 6 PLY

Wheelbase (mm)1290

Length/Width/Height (mm)2155 X 1240 X 1280

Fuel Capacity18 L

Electrical Outlet Connector2 DC 12V 10A 120W

InstrumentationDigital instrument panel with odometer, speedmeter, Tripmeter, RPM, transmission position, fuel gauge, Hi-Temp/Low-Battery lights, high beam light, EFI checking, differential indicator, 2WD/4WD indicator
